Resisting sticking, cracking, corrosion and breakdown.
Enduring high&low temperature and voltage.
Excellent lubricating property.
Virgin material.
Remarks: Multi-layer plastic tube is made of several materials.
We can make production according to customer's specifications including the material, color, dimension and packaging.
| Material | OD(mm) | ID(mm) | MIN. Thickness(mm) | Tolerance of Thickness (mm) | Tolerance of ID/OD(mm) |
| PE | 2.1-12.0 | 1.5-10 | ≥0.2 | ≤0.10 | ≥±0.05 |
| POM | 2.5-12.0 | 1.5-10 | ≥0.20 | ≤0.10 | ≥±0.05 |
| PP | 3.0-12.0 | 2.5-10 | ≥0.25 | ≤0.10 | ≥±0.05 |
| PBT | 3.0-12.0 | 2.4-10 | ≥0.30 | ≤0.10 | ≥±0.05 |
| PA6 | 5.0-12.0 | 4.0-10 | ≥0.5 | ≤0.20 | ≥±0.1 |
| PA66 | 4.0-12.0 | 3.2-10 | ≥0.35 | ≤0.10 | ≥±0.075 |
| PA12 | 4.0-12.0 | 3.2-10 | ≥0.35 | ≤0.10 | ≥±0.1 |
| TPU | 5.0-12.0 | 4.0-10 | ≥0.5 | ≤0.2 | ≥±0.25 |
| PTFE | 2.7-12.0 | 2.1-10 | ≥0.3 | ≤0.10 | ≥±0.05 |
| Multi-layer plastic tube | 2.7-12.0 | 2.1-10 | ≥0.3 | ≤0.10 | ≥±0.05 |
The possible applications of plastic tube are unlimited! It is widely used on vessel auto, motorcycle, bicycle, machinery, textile industrial, medical facility and so on.
